Revel Bikes Announce The New Ranger
(Re)Built to Explore.
The original Ranger brought the efficiency and performance of the Canfield Balance Formula to a Cross Country bike, and it has been punching well above its weight class since its introduction in 2020. The reworked and revitalized New Ranger cranks things up another notch with a redesigned rear end offering more lateral stiffness, increased tire and chainring clearance, and a one-tool system for improved serviceability and longer bearing life.
Revel has taken one of the favorite bikes in the lineup and made it even better! The new
Ranger features an all-new rear triangle, links, hardware, and SRAM’s forward-compatible UDH Derailleur hanger.
The new Ranger shares the effective and simple hardware design
introduced and raved about with Rail29. This time it was taken further and gave the new Ranger a collet axle design with larger 15mm bearings on the lower rearward pivot. This increases frame stiffness, improves clearance, makes for easier maintenance, and a quieter ride.
Revel has created and introduced an all-new set of links to take advantage of this new hardware design and has adapted the SRAM’s UDH derailleur hanger to keep the New Ranger compatible with the latest and greatest drivetrain technologies.
Details and Key Features:
• Updated Paint and Decals - Now available in "Tang" which is borrowed from the Rail 27.5, and the classic "De La Coal" color, with new copper/gold decals.
• New Rear Triangle on the new Ranger has an improved carbon layup
that achieves 20% more stiffness with no added weight!
• All New links
• All New hardware package - Titanium shock mounting hardware
• SRAM UDH derailleur hanger and ET drivetrain compatibility
• Custom shock tune from RockShox
• Bolstered Frame Protection - A rear triangle debris guard now comes standard on every New Ranger frame along with robust chainstay protection, as found on Rail29, which makes for a quieter ride
• Threaded Bottom Bracket
• Integrated headset - IS 52/42 standard
• Fully guided internal routing
• Multiple bottle and accessory mount options - 3 sets (2 on size small)
Image Assets | Landing Page
Build | XO EAGLE TRANSMISSION | XX EAGLE TRANSMISSION |
MSRP | $8,499 | $11,499 |
Frame | Revel Ranger 29″ 115mm Travel | Revel Ranger 29″ 115mm Travel |
Fork | RockShox SID Ultimate 120mm | RockShox SID Ultimate 120mm |
Shock | RockShox SID Luxe Ultimate | RockShox SID Luxe Ultimate |
Wheelset | Industry Nine Trail S Rims
Industry Nine 1/1 Hubs | Revel RW27 28H Rims
Industry Nine Hydra Hubs |
Headset | Cane Creek 40-series | Cane Creek 40-series |
Tubeless | Stans No tubes Single shots x2 | Stans No tubes Single shots x2 |
Tires | Maxxis Dissector 29″ x 2.4″ EXO Front Maxxis Rekon 29″ x 2.4″ EXO Rear | Maxxis Dissector 29″ x 2.4″ EXO Front
Maxxis Rekon 29″ x 2.4″ EXO Rear |
Bars | RaceFace NEXT R 35
800mm x 20mm Rise | RaceFace NEXT R 35
800mm x 20mm Rise |
Stem | RaceFace Turbine R 35 x 40mm | RaceFace Turbine R 35 x 40mm |
Dropper | Crank Brothers Highline 7
SM (31.6mm x 125mm)
MD (31.6mm x 150mm)
LG (31.6mm x 170mm)
XL (31.6 x 200mm) | Rockshox Reverb AXS
SM (31.6mm x 125mm)
MD (31.6mm x 150mm)
LG (31.6mm x 170mm)
XL (31.6 x 170mm) |
Saddle | WTB Volt CroMo Black | WTB Volt CroMo Black |
Brakes | SRAM Level Silver | SRAM Level Ultimate |
Rotors | SRAM HS2 6-Bolt
180mm Front / 160mm Rear | SRAM HS2 6-Bolt
180mm Front / 160mm Rear |
Shifter | SRAM AXS Shifter Pod Ultimate | SRAM AXS Shifter Pod Ultimate |
Rear Derailleur | SRAM X0 ET | SRAM XX ET |
Chain | SRAM X0 ET T-Type | SRAM XX ET T-Type |
Cassette | SRAM X0 ET T-Type | SRAM XX ET T-Type |
Crankset | SRAM X0 Eagle T-Type 170mm 32t | SRAM XX Eagle T-Type 170mm 32t |
Bottom Bracket | SRAM DUB BSA Wide | SRAM DUB BSA Wide |
Grips | Lizard Skins Charger Evo Grip Black | Lizard Skins Charger Evo Grip Black |
Seatpost Collar | Revel 34.9mm Dia | Revel 34.9mm Dia |
| FRAME ONLY |
MSRP | $3,599 |
Frame | Revel Ranger 29″ 115mm Travel |
Shock | RockShox SID Luxe Ultimate |
Headset | Cane Creek 40-series |
Seatpost Collar | Revel 34.9mm Dia |
